| Categories | Screw Conveyor |
|---|---|
| Certification: | CE, ISO9001:2015 |
| MOQ: | 1 |
| Price: | US $1,500-2,800 / s |
| Place of Origin: | China |
| Brand Name: | DY |
| Delivery Time: | 7-14 work days |
| Model NO.: | LS-160 |
| Material: | Stainless Steel |
| Material Feature: | Heat Resistant |
| Energy Saving: | Energy Saving |
| Warranty: | 1 Year |
| Color: | Multi Color |
| Condition: | New |
| After-sales Service: | Online Video |
| Length: | Customized |
| Installation: | Engineer Guide |
| Operation: | Automatic Continuous Operation |
| Working Angle: | 0-60 Degree |
| Voltage: | 220V/380/as Your Request |
| Transport Package: | Standard Export Wooded Case |
| Specification: | screw diameter 160mm |
| Trademark: | DY |
| Origin: | China |
| HS Code: | 8428399000 |
| Production Capacity: | 90 Set/Sets Per Month |
| Company Info. |
| Xinxiang Dayong Vibration Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
This screw conveyor is a customizable machine. We can design and manufacture a screw conveyor according to customers' specific requirements. The screw conveyor also be called as other name in different country, for example, sometimes will also named it as pipe screw conveyor; auger conveyor; trough shaped screw conveyor; screw feeder; U-type screw conveyor and so on.
| Model | Diameter (mm) | The distance of blades(mm) | Speed (rpm) | Capacity (t/m³) | Speed (rpm) | Capacity (t/m³) | Speed (rpm) | Capacity (t/m³) | Speed (rpm) | Capacity (t/m³) |
| D | S | n | φ=0.33 | n | φ=0.33 | n | φ=0.33 | n | φ=0.33 | |
| LS100 | 100 | 100 | 140 | 2.2 | 112 | 1.7 | 90 | 1.4 | 71 | 1.1 |
| LS125 | 125 | 125 | 125 | 3.8 | 100 | 3.0 | 80 | 2.4 | 63 | 1.9 |
| LS160 | 160 | 160 | 112 | 7.1 | 90 | 5.7 | 71 | 4.5 | 56 | 3.6 |
| LS200 | 200 | 200 | 100 | 12.4 | 80 | 9.9 | 63 | 7.8 | 50 | 6.2 |
| LS250 | 250 | 250 | 90 | 21.8 | 71 | 17.2 | 56 | 13.6 | 45 | 10.9 |
| LS315 | 315 | 315 | 80 | 38.8 | 63 | 30.5 | 50 | 24.2 | 40 | 13.4 |
Loose materials such as powder, granular and small piece material , which includes: clay powder, pulverized coal, cement, sand, grain, small piece of coal , cobble, and cast iron filings, etc. While it is not applicable for materials with high viscosity and easy to be curdled. Widely applied:It is widely used for the loose cement transportation from cement warehouse to mixer or from cement warehouse to compounding machine in concrete mixing plant
|
