Bulk CAT5e SFTP Cable 24AWG Solid Copper 100MHz Gigabit LSZH Shielded LAN Cable for Data Center & Industrial Networks

Categories SFTP CAT5E Cable
Brand Name: ITI-LINK
Model Number: ITI-CT5SF-009
Certification: UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Place of Origin: SHENZHEN
MOQ: 1000pcs
Price: 50$-100$
Payment Terms: T/T
Supply Ability: 2000pcs/day
Delivery Time: 15-45Days
Packaging Details: Color Box+Packing Box 38*38*24cm
Conductor Gauge: 24 AWG
Cable Type: CAT5E
Jacket Color: Gray
Cable Length: 305m
Frequency: 100MHz
Cable Shielding: SFTP
Jacket Material: PVC
Conductor Material: Copper
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Bulk CAT5e SFTP Cable 24AWG Solid Copper 100MHz Gigabit LSZH Shielded LAN Cable for Data Center & Industrial Networks

Bulk CAT5e SFTP Cable 24AWG Solid Copper 100MHz Gigabit LSZH Shielded LAN Cable
Product Overview

The ITI-LINK ITI-CT5SF-030 CAT5e SFTP Cable is a professional-grade shielded LAN cable engineered for reliable Gigabit Ethernet infrastructure. Designed for data center cable installations and industrial network deployments, this CAT5e SFTP cable ensures stable connectivity and efficient data communication for modern networking systems.

Performance & Transmission Stability

With support for 100MHz bandwidth and up to 1Gbps transmission speed, this CAT5e shielded Ethernet cable delivers stable and high-speed data transfer. The SFTP shielding structure significantly reduces electromagnetic interference (EMI) and crosstalk, ensuring reliable performance in high-density network environments such as data centers and industrial networks.

Structure & Materials

The cable is constructed with 24AWG solid oxygen-free copper conductors, four precision twisted pairs, aluminum foil shielding, and braided protection. This robust structure improves signal integrity while minimizing attenuation. The outer jacket is available in PVC or LSZH material, providing flexibility, durability, and enhanced fire safety for professional installations.

Application Value

This CAT5e SFTP shielded LAN cable is ideal for structured cabling systems across enterprise networks, industrial automation systems, smart building infrastructure, and data center networking. It supports stable connections for routers, switches, servers, IP cameras, and automation equipment.

Technical Specifications
Construction & Electrical Properties
Construction ItemDescriptionElectrical PropertyValue
Conductor
MaterialBare Solid Copper (elongation: 19-24%)Conductor Resistance at 20°C≤ 9.5 Ω / 100m
OD24 AWGResistance unbalance within a pair≤ 2%
Insulation
MaterialHDPE 8303Insulation Resistance at 20°C>1500 MΩ / 100m
OD0.90 ± 0.02 mmMutual capacitance5600 pF / 100m MAX
Average THK0.20 mmCapacitance unbalance pair to ground≤ 160 pF / 100m
Color1p: white + 2 blue stripes & blue
2p: white + 2 orange stripes & orange
3p: white + 2 green stripes & green
4p: white + 2 brown stripes & brown
Characteristic impedance at 100MHz100 ± 15 Ω
Pair Twist
Lay & Direction1p: S=20.0 mm (28%)
2p: S=17.5 mm (24%)
3p: S=22.0 mm (32%)
4p: S=15.5 mm (21%)
Dielectric Strength Test VoltageNo breakdown
Transmission Properties - CAT5e
Frequency (MHz)Attenuation Max (dB/100m)Propagation Delay Max (ns/100m)Return Loss Min (dB)NEXT Min (dB)
14.055524556.27
85.77546.734551.75
106.47545.382550.3
168.255432547.24
209.27542.052545.78
2510.42541.224.3244.33
31.2511.72540.4423.6442.88
5015.07539.0922.2139.82
62.516.99538.5521.5438.36
10021.98537.620.1135.3
Applications
  • Industrial Automation Networks: Reliable CAT5e SFTP industrial network cable for connecting PLC controllers, industrial sensors, robotic systems, and smart manufacturing equipment in factory automation environments.
  • Data Center Network Infrastructure: Designed as a high-performance data center cable for connecting servers, switches, routers, and storage systems while maintaining stable Gigabit Ethernet transmission.
  • Enterprise Office LAN Systems: This CAT5e shielded LAN cable supports stable connectivity for enterprise networks, enabling high-speed communication for workstations, VoIP phones, printers, and wireless access points.
  • 5G Communication & Telecom Rooms: Ideal shielded Ethernet cable for telecommunications cabinets, communication base stations, and equipment rooms where EMI protection and reliable signal transmission are essential.
  • Security Surveillance Systems: Suitable for IP camera networks, NVR systems, and smart security infrastructure, ensuring stable video data transmission and reliable connectivity.
CAT5e SFTP Cable product image showing construction and packaging
