✅ Product Description

Our Rental LED Display Panels provide a professional solution for concerts, festivals, exhibitions, and large-scale indoor & outdoor events.
With P3.91 pixel pitch, 7680Hz ultra-high refresh rate, and high brightness waterproof design, this LED video wall delivers crystal-clear, flicker-free visuals for both live broadcast and on-site audiences.

Designed with dual power & signal backup, modular structure, and hard link connection system, it ensures stable performance even in critical moments.
Whether for concert stages, trade shows, or corporate events, this LED screen rental system offers flexible installation, reliable operation, and stunning visual impact.

During a recent large outdoor music festival with over 50,000 attendees, 360 panels were installed in a curved 120° arc configuration.
The system operated continuously for 18 hours per day in heavy rain and high temperature without a single panel failure, achieving:

• Setup Time: 5.5 hours

• Uptime: 99.97%

• Color Uniformity: ΔE < 2

• Power Consumption: 280W/m² (30% lower than industry average)

✅ Key Features

• 7680Hz ultra-high refresh rate for smooth, flicker-free visuals, perfect for live broadcast and camera shooting

• Dual power & signal backup system to prevent blackouts and ensure continuous operation

• High brightness & waterproof design (IP65 front/rear) for both indoor and outdoor rental use

• Lightweight die-casting aluminum cabinet with quick-lock system for fast installation and dismantling

• Front and rear maintenance design for flexible setup and easy servicing

• Hard Link connection system for stronger panel stability, perfect alignment, and zero signal delay

• NovaStar A5plus control system for superior image processing and accurate color reproduction

• Seamless splicing and excellent color uniformity for a premium visual experience

• Modular design for quick replacement and efficient maintenance

• Customizable curved or flat configurations for creative stage designs

✅ LED Screen Technical Specifications

Module Parameters

• Module Size: 250 × 250 mm

• Module Dots: 64 × 64

• Pixel Pitch: 3.9 mm



Cabinet Parameters

• Cabinet Size: 500 × 1000 mm

• Cabinet Resolution: 128 × 256

• Cabinet Material: Die Casting Aluminum

• Cabinet Weight: 13 kg

Performance Specifications

• LED Chip: Kinglight SMD1415 Black 3-in-1

• Refresh Rate: 7680 Hz

• Gray Scale: 4096–65535

• Color Grayscale: 32 bit

• Driving Type: 1/32 Scan

• Brightness: 4500–5000 nits

• Viewing Angle: H160° / V160°

• Blind Spot Rate: <0.0001

• Signal Processing: ≥10 bit

• Lifetime: 100,000 hours

Power & Environment

• AC Input Voltage: 110V

• Frequency: 50/60Hz

• Power Consumption (Typical): 250W/m²

• Working Temperature: -20°C to 50°C

• Storage Temperature: -25°C to 65°C

• Working Humidity: 10%–80% RH (non-condensation)

• IP Rating: IP65 Front & Rear

Signal & Playback

• Signal Transmission:

  • CAT5 Cable: <100m

  • Single Mode Fiber: <10km

• Video Sources: Cable TV, DVD, PC, RGBHV, YUV, Composite Video

• Playback Mode: Video, animation, text (free combination)

• Image Adjustment: White balance, contrast, brightness, single module tuning

• Image Switching: VGA synchronous with frame

✅ Application Scenarios

• Concerts & Music Festivals

• Sports Events & Competitions

• Exhibitions & Trade Shows

• Shopping Malls & Retail Promotions

• Corporate Events & Conferences

• Church stages & large indoor venues

Suitable for both indoor LED display and outdoor LED screen applications.

✅ Installation & Maintenance

• Quick setup with hard link design, reducing installation time by 50%

• Front & rear maintenance for flexible access

• Seamless splicing for smooth and continuous display

• Optional curved connection for creative stage designs

• Even non-technical teams can complete installation within minutes, saving time and labor costs



✅ Packing & Shipment

LED panels are packed in high-quality flight cases:

• Anti-shock foam protection

• Stackable for easy transport and storage

• Waterproof and dustproof design

• Each case holds 6–8 panels (500×500mm / 500×1000mm cabinets)



Shipping options:

• Air freight

• Sea freight

• Express delivery

All shipments are inspected under strict QC standards before delivery.

✅ Why Choose Guide Visual

Guide Visual is a professional LED display manufacturer with over 13 years of experience in the LED screen industry.

• Factory-direct LED solutions with professional technical support

• Competitive pricing with consistent quality assurance

• NovaStar A5plus control system

• Self-developed cabinets with strong anti-collision performance

• Stable signal connection with no black screen risk

• Trusted by customers across Europe, Middle East, Africa, and Southeast Asia

Guide Visual — your trusted partner in LED display solutions.

Our Machine
Guide owns 10000 square meters factory, we have many advanced machines. Our production equipment is largely imported, ensuring high precision and quality in every product we manufacture. This commitment to advanced technology allows us to meet the highest industry standards and deliver exceptional results for our clients. Quality and accuracy are at the core of our operations.

Our Workshop
All of Guide staff are experienced with strict training. Each Guide led display order will be tested 72 hours before shipping. our led video wall undergo rigorous testing and aging processes to ensure reliability and performance. This thorough quality control guarantees that every item meets our high standards before reaching our customers, providing them with confidence in the durability and functionality of our offerings. Quality is our commitment !

Packing Method
After aging and testing, we package each led display in flight cases to ensure maximum safety during transit. This robust packaging protects the displays from damage, guaranteeing that they arrive in perfect condition. Our commitment to quality extends to every aspect of our service.
