XLPO/LSZH Solar PV Cable 2.5mm2 4mm2 6mm2 10mm 16mm for Solar Panel System

APPLICATION

The cables are commonly used in solar photovoltaic (PV) systems because of their excellent properties, such as high durability, low fire risk, and environmental safety.

CONSTRUCTION

Conductor: Class 5 tinned copper conductors
Insulation: Halogen free flame-retardant insulation material for solar cables
Outer sheath:Halogen free flame retardant sheath material for solar cables

CHARACTERISTIC

Voltage Rating: Uo/U:1.0/1.0kV Um:1.5kV
Maximum operating temperature of conductor:+120℃
Operating ambient temperature: -40℃~+90℃
Cable laying temperature:Not less than -25℃
Minimum Bending Radius: 6D

SPECIFICATIONS

Cross section(mm²)	Conductor Construction(no/mm)	Conductor Stranded OD.max(mm)	Cable OD.(mm)	Approximate weight of cable kg/km	Max Conductor Resistance(Ω/km,20°C)
1×1.5	48/0.20	1.58	4.8	35	13.7
1×2.5	77/0.20	2.02	5.2	47	8.21
1×4	56/0.285	2.46	5.7	64	5.09
1×6	84/0.285	3.01	6.3	86	3.39
1×10	77/0.40	4.1	7.2	128	1.95
1×16	7×17/0.40	5.5	8.9	196	1.24
1×25	7×27/0.40	6.7	10.7	299	0.795
1×35	7×38/0.40	8.2	12.4	407	0.565
1×50	19×20/0.40	10.0	14.6	571	0.393
1×70	19×28/0.40	11.6	16.4	773	0.277
1×95	19×38/0.40	13.5	18.5	1024	0.210
1×120	24×38/0.40	14.4	19.8	1266	0.164
1×150	30×38/0.40	16.2	22.2	1584	0.132
1×185	37×38/0.40	18.2	25.0	1967	0.108
1×240	48×38/0.40	20.6	27.8	2518	0.0817

24 Pairs Double Shielded Twisted Pair Computer Cable Armoured Overall Screen 12 Pair Instrument Cable 1

24 Pairs Double Shielded Twisted Pair Computer Cable Armoured Overall Screen 12 Pair Instrument Cable 2

24 Pairs Double Shielded Twisted Pair Computer Cable Armoured Overall Screen 12 Pair Instrument Cable 3

24 Pairs Double Shielded Twisted Pair Computer Cable Armoured Overall Screen 12 Pair Instrument Cable 4

1.You are manufacturer or trader ?

We are a professional ISO certified cable manufacturer with more than 20 years experience.

2.How can I get the quotation of the products ?

Pls send your inquiry to us,our sales manager will offer you within 12 hours.

3.What does your company do regarding quality control?

1) All raw materials we selected are the highest quality. 2) Professional and skillful workers care every details in handling the producing. 3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?

Yes,OEM & ODM order is warmly welcomed.Our engineers will give you the professional suggestions.

5.What is your payment term ?

Our payment term is usually T/T 30% in advanced, the balance before shipping or L/C at sight.

Product Tags:


*From:	Your email address is incorrect!
*To:	Zhongdong Cable Co., Ltd.
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Solar Cable
Brand Name:	DC Panel Solar Wire
Model Number:	H1z2z2-k
Certification:	IEC,CE,ISO,TUV
Place of Origin:	Hebei，China
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	L/C,T/T
Supply Ability:	100KM/Week
Delivery Time:	7-30 days based on different qty
Packaging Details:	Rolls, Wooden Drums, Steel Drums, Reels or customized
Voltage:	1.0/ 1.5kV
Armoring:	No
Insulation:	PVC
Core:	Multi cores
Temperature range:	- 30℃ to + 70℃
Sheathed:	PVC
