2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System

2 Axle Cargo Container Trailer 40FT Shipping Container Trailer Light Weight

Description:

Main application

Skeleton container trailer is a kind of semi-trailer frame for container transportation. Mainly used in shipyard, port, route, highway, transfer station, bridge, tunnel, multi-modal transport logistics system.

Advantages:

• Quickly stevedoring

It can be quickly loaded and unloaded, and can be directly and conveniently transferred from one conveyance to another.

• Meeting needs

It is convenient for cargo loading and unloading, and meets the individual needs of customers. The skeletal trailer made by Huilong factory has stable quality, reliable performance.

• Paint

One coat of rust proof paint, two coats of paint

• Testing

We will test the quality of the trailer before delivery

Specifications:

DIMENSIONS
Tare Weight	4800KGS	Payload	35000KGS
Overall Length	12400mm	Overall Width	2480mm
Technical Data
Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm,height 500mm; Bottom Flange 16mm,width 140mm.
Axle	2 axles
	Brand name: FUWA
Suspension	Mechanical suspension with 10pcs leaf spring
Spring	Leaf spring
King Pin	FUWA brand 2” Bolt-in King Pin
Landing Gear	FUWA brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim	9.0-22.5 steel wheel rim
Twist Lock	12nos. of ISO twist lock for 1x20ft container, 2x20ft container, 1x40ft container
Tyre	12R22.5 tire, 8PCS
Spare Tyre	One set of spare tire including a carrier
Braking System	WABCO RE 4 relay valve; T30/30 Spring brake chamber; 45L air tanks
Painting	Complete Chassis sand blasting to clean rust; 1 coat of anticorrosive prime, 2 coats of final paint
Accessories	One standard tool box, one spare tyre carrier
